Features:
Metal gear train ensures durability and longevity.
Great replacement for RTR crawler, truck and buggy servos.
Excellent choice for budget-conscious customers.
Same height as SW0231MG.
Specifications:Torque @ 4.8v – 20.0kg/278.0oz-in
Torque @ 6v – 25.0kg/347.0oz-in
Speed @ 4.8v – 0.19 sec/60 deg
Speed @ 6v – 0.16 sec/60 deg
Dimensions L x W x H (mm): 40.7 x 20.0 x 42.4
Weight: 69.0g
Operating Temperature: 14° – 122°F (-10° – 50°C)
Running Current (no load): 300mA @4.8V, 350mA @6.0V
Stall Current (at locked): 8000mA @4.8V, 10,000mA @6.0V
Idle Current: 5mA @4.8V, 5mA @6.0V
Wire Length: 300 /- 5mm
Output Gear Spline: 25 Tooth
Bearings: 2BB
Operating Travel: 120° (1000 → 2000 µ second)
Neutral Position: 1500 µ second
Pulse Width Range: 800 → 2200 µ second
Maximum Travel: Appx 164° (800 → 2200 µ second)
Refresh Rate: 333 Hz
Motor Type: Coreless
